5.10 o: Keypad-Related Settings
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 363
To start the drive again after you push to stop operation, turn the external Run command OFF and ON again.
■ o2-03: User Parameter Default Value
No.
(Hex.)
Name Description
Default
(Range)
o2-03
(0507)
User Parameter Default
Value
Sets the function to keep the settings of changed parameters as user parameter defaults to use during
initialization.
0
(0 - 2)
When you set o2-03 = 1 [Set defaults], the drive saves changed parameter settings as user parameter setting values in
a part of the memory that is isolated from drive parameters.
When you set A1-03 = 1110 [Initialize Parameters = User Initialization] to initialize the drive, the drive resets the
internal parameter setting values to those user parameter setting values.
0 : No change
1 : Set defaults
Saves changed parameter setting values as user default settings.
Set o2-03 = 1 then push to save the user parameter setting values. After the drive saves the setting value, o2-03
automatically resets to 0.
2 : Clear all
Deletes all of the saved user parameter setting values.
Set o2-03 = 2 then push to clear the user parameter setting values. The drive will automatically reset o2-03 to 0. If
you delete the user parameter setting values, you cannot set A1-03 = 1110 to initialize parameters.
■ o2-04: Drive Model (KVA) Selection
No.
(Hex.)
Name Description
Default
(Range)
o2-04
(0508)
Drive Model (KVA)
Selection
Sets the Drive Model code. Set this parameter after you replace the control board. Determined by the drive
(-)
NOTICE: Set o2-04 [Drive Model Selection] correctly. If you set this parameter incorrectly, it will decrease drive performance, cause
the protection function to operate incorrectly, and cause damage to the drive.
Note:
When the setting value of o2-04 changes, related parameter setting values also change. Refer to Defaults by Bypass and Drive Model on page
688 for more information.
These tables list the relation between o2-04 setting values and drive models.
o2-04 Setting Drive Model
65 2011
67 2017
68 2024
6A 2031
6B 2046
6D 2059
6E 2075
6F 2088
70 2114
72 2143
73 2169
74 2211
75 2273
o2-04 Setting Drive Model
95 4005
97 4008
99 4011
9A 4014
9B 4021
9D 4027
9E 4034
9F 4040
A0 4052
A2 4065
A3 4077
A4 4096
A5 4124
