5.10 o: Keypad-Related Settings
372 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
No. Item
Number of
Characters
Description
1 Attribute 2 [02] shows that the record is a monitor data record.
2 File number 4 The [xxx] part of the [GLOG0xxx.csv] filename is a 3-digit decimal number in hexadecimal format.
3 Time stamp 12 Data log data was retrieved (YYMMDDHHMMSS)
4 Log Monitor Data 1 4 Monitor number selected by o5-03 [Log Monitor Data 1]
5 Log Monitor Data 2 4 Monitor number selected by o5-04 [Log Monitor Data 2]
: : : :
13 Log Monitor Data 10 4 Monitor number selected by o5-12 [Log Monitor Data 10]
14 Reserved 4 -
15 Encoding data 4 Encoding data for log monitor data 1 through 10 (Hex.)
Bits 0 through 9 show the encoding of log monitor data 1 1 through 10. A bit value of 1 shows that the data represents a
negative value. (Log monitor data 1 through 10 is absolute value data without encoding)
Example when log monitor data 2, 5, and 8 show negative values: Bits 1, 4, and 7 have values of 1, and the encoding data
= 0010010010 (Bin.) = 0092 (Hex.)
16 File number 6 Row number (Hex.) in the data log file
■ o5-01: Log Start/Stop Selection
No.
(Hex.)
Name Description
Default
(Range)
o5-01
(1551)
RUN
Log Start/Stop Selection Sets the data log function. This parameter is only available on an HOA keypad. 0
(0 - 1)
Note:
You must insert a compatible SD cart into the keypad before you enable this parameter.
0 : OFF
Stops the data log.
1 : ON
Starts the data log as specified by the sampling cycle set in o5-02 [Log Sampling Interval].
■ o5-02: Log Sampling Interval
No.
(Hex.)
Name Description
Default
(Range)
o5-02
(1552)
RUN
Log Sampling Interval Sets the data log sampling cycle. This parameter is only available on an HOA keypad. 100 ms
(100 - 60000 ms)
■ o5-03: Log Monitor Data 1
No.
(Hex.)
Name Description
Default
(Range)
o5-03
(1553)
RUN
Log Monitor Data 1 Sets the data log monitor. This parameter is only available on an HOA keypad. 101
(000, 101 - 1299)
Note:
Set the U monitor number you want to log.
For example, to display U1-01 [Frequency Reference], set o5-03 = 101. When it is not necessary to set a data log monitor, set this parameter
to 000.
