Parameter Details
5
5.11 S: Special Applications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 381
5 : Tuesday
6 : Wednesday
7 : Thursday
8 : Friday
9 : Saturday
10 : Sunday
â– S2-04: Timer 1 Sequence Selection
No.
(Hex.)
Name Description
Default
(Range)
S2-04
(3209)
Timer 1 Sequence Selection Sets the drive response when sequence timer 1 is active. 0
(0 - 2)
0 : Digital Out Only
1 : Run
2 : Run - PID Disable
3 : Allow Alternation
â– S2-05: Timer 1 Reference Source
No.
(Hex.)
Name Description
Default
(Range)
S2-05
(320A)
Timer 1 Reference Source Selects the frequency reference source to run the drive when sequence timer 1 is active (only
applicable when S2-04 > 0 [Timer 1 Sequence Selection ≠Digital Out Only]).
0
(0 - 8)
0 : Operator (d1-01/YA-01)
1 : Operator (d1-02/YA-02)
2 : Operator (d1-03/YA-03)
3 : Operator (d1-04/YA-04)
4 : Terminals
5 : Serial Com
6 : Option PCB
8 : Set by b1-01
Note:
For reference source 0 to 3, the drive will use d1-xx frequency reference when PID mode is disabled and YA-xx setpoint when PID is enabled.
â– S2-06: Timer 2 Start Time
No.
(Hex.)
Name Description
Default
(Range)
S2-06
(320B)
Timer 2 Start Time Sets the start time for timer 2. 12:00
(12:00 AM - 11:59 PM)
Note:
• Default is when o4-22 = 1 [Time Format = 12 Hour Clock]. When o4-22 = 0 [24 Hour Clock], default is 00:00. When o4-22 = 2 [12 Hour
JP Clock], default is 00:00 AM.
• Range is when o4-22 = 1. When o4-22 = 0, range is 00:00 to 24:00. When o4-22 = 2, range is 00:00 AM to 11:59 PM.
â– S2-07: Timer 2 Stop Time
No.
(Hex.)
Name Description
Default
(Range)
S2-07
(320C)
Timer 2 Stop Time Sets the stop time for timer 2. 12:00
(12:00 AM - 11:59 PM)
