Parameter Details
5
5.11 S: Special Applications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 383
â– S2-11: Timer 3 Start Time
No.
(Hex.)
Name Description
Default
(Range)
S2-11
(3210)
Timer 3 Start Time Sets the start time for timer 3. 12:00
(12:00 AM - 11:59 PM)
Note:
• Default is when o4-22 = 1 [Time Format = 12 Hour Clock]. When o4-22 = 0 [24 Hour Clock], default is 00:00. When o4-22 = 2 [12 Hour
JP Clock], default is 00:00 AM.
• Range is when o4-22 = 1. When o4-22 = 0, range is 00:00 to 24:00. When o4-22 = 2, range is 00:00 AM to 11:59 PM.
â– S2-12: Timer 3 Stop Time
No.
(Hex.)
Name Description
Default
(Range)
S2-12
(3211)
Timer 3 Stop Time Sets the stop time for timer 3. 12:00
(12:00 AM - 11:59 PM)
Note:
• Default is when o4-22 = 1 [Time Format = 12 Hour Clock]. When o4-22 = 0 [24 Hour Clock], default is 00:00. When o4-22 = 2 [12 Hour
JP Clock], default is 00:00 AM.
• Range is when o4-22 = 1. When o4-22 = 0, range is 00:00 to 24:00. When o4-22 = 2, range is 00:00 AM to 11:59 PM.
â– S2-13: Timer 3 Day Selection
No.
(Hex.)
Name Description
Default
(Range)
S2-13
(3212)
Timer 3 Day Selection Sets the days for which sequence timer 3 is active. 0
(0 - 10)
0 : Timer Disabled
1 : Daily
2 : Mon - Fri
3 : Sat - Sun
4 : Monday
5 : Tuesday
6 : Wednesday
7 : Thursday
8 : Friday
9 : Saturday
10 : Sunday
â– S2-14: Timer 3 Sequence Selection
No.
(Hex.)
Name Description
Default
(Range)
S2-14
(3213)
Timer 3 Sequence Selection Sets the drive response when sequence timer 3 is active. 0
(0 - 2)
0 : Digital Out Only
1 : Run
2 : Run - PID Disable
3 : Allow Alternation
