5.11 S: Special Applications
384 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
â– S2-15: Timer 3 Reference Source
No.
(Hex.)
Name Description
Default
(Range)
S2-15
(3214)
Timer 3 Reference Source Selects the frequency reference source to run the drive when sequence timer 3 is active (only
applicable when S2-14 > 0 [Timer 3 Sequence Selection ≠Digital Out Only]).
0
(0 - 8)
0 : Operator (d1-01/YA-01)
1 : Operator (d1-02/YA-02)
2 : Operator (d1-03/YA-03)
3 : Operator (d1-04/YA-04)
4 : Terminals
5 : Serial Com
6 : Option PCB
8 : Set by b1-01
Note:
For reference source 0 to 3, the drive will use d1-xx frequency reference when PID mode is disabled and YA-xx setpoint when PID is enabled.
â– S2-16: Timer 4 Start Time
No.
(Hex.)
Name Description
Default
(Range)
S2-16
(3215)
Timer 4 Start Time Sets the start time for timer 4. 12:00
(12:00 AM - 11:59 PM)
Note:
• Default is when o4-22 = 1 [Time Format = 12 Hour Clock]. When o4-22 = 0 [24 Hour Clock], default is 00:00. When o4-22 = 2 [12 Hour
JP Clock], default is 00:00 AM.
• Range is when o4-22 = 1. When o4-22 = 0, range is 00:00 to 24:00. When o4-22 = 2, range is 00:00 AM to 11:59 PM.
â– S2-17: Timer 4 Stop Time
No.
(Hex.)
Name Description
Default
(Range)
S2-17
(3216)
Timer 4 Stop Time Sets the stop time for timer 4. 12:00
(12:00 AM - 11:59 PM)
Note:
• Default is when o4-22 = 1 [Time Format = 12 Hour Clock]. When o4-22 = 0 [24 Hour Clock], default is 00:00. When o4-22 = 2 [12 Hour
JP Clock], default is 00:00 AM.
• Range is when o4-22 = 1. When o4-22 = 0, range is 00:00 to 24:00. When o4-22 = 2, range is 00:00 AM to 11:59 PM.
â– S2-18: Timer 4 Day Selection
No.
(Hex.)
Name Description
Default
(Range)
S2-18
(3217)
Timer 4 Day Selection Sets the days for which sequence timer 4 is active. 0
(0 - 10)
0 : Timer disabled
1 : Daily
2 : Mon - Fri
3 : Sat - Sun
4 : Monday
5 : Tuesday
6 : Wednesday
7 : Thursday
8 : Friday
