5.14 Z: Bypass Parameters
444 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
■ Z2-15: Digital Input 7 Invert Select
No.
(Hex.)
Name Description
Default
(Range)
Z2-15
(8571)
Digital Input 7 Invert Select Inverts the output of the function selected in Digital Input 7. 0
(0, 1)
0 : Normal (Non-inverted)
1 : Inverted
■ Z2-16: Digital Input 8 Invert Select
No.
(Hex.)
Name Description
Default
(Range)
Z2-16
(8572)
Digital Input 8 Invert Select Inverts the output of the function selected in Digital Input 8. 0
(0, 1)
0 : Normal (Non-inverted)
1 : Inverted
■ Digital Input Setting Value
Selects a function set with Z2-01 to Z2-08.
0: Not Used
Setting Value Function Description
0 Not Used Use this setting for unused terminals or to use terminals in through mode.
Input terminals programmed to this value will have no effect on the operation of the bypass package. It is possible,
however, to read the status of the terminal over various serial communications protocols.
It is possible to program multiple digital input terminals to Not Used [Z2-0x = 0].
1: Drive S1 Passthrough
Setting Value Function Description
1 Drive S1 Passthrough Drive Multi-function input S1.
2: Drive S2 Passthrough
Setting Value Function Description
2 Drive S2 Passthrough Drive Multi-function input S2.
3: Drive S3 Passthrough
Setting Value Function Description
3 Drive S3 Passthrough Drive Multi-function input S3.
4: Drive S4 Passthrough
Setting Value Function Description
4 Drive S4 Passthrough Drive Multi-function input S4.
5: Drive S5 Passthrough
Setting Value Function Description
5 Drive S5 Passthrough Drive Multi-function input S5.
6: Drive S6 Passthrough
Setting Value Function Description
6 Drive S6 Passthrough Drive Multi-function input S6.
