7.4 208 V Enclosed Model Specifications
534 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
Table 7.7 208 V Enclosed Ratings
Model D088 D114 D143 D169 D211 D273
Maximum Applicable Motor Output
(HP)
*2
30 40 50 60 75 100
Input
Rated Input Current (A) 90.4 116.4 145.4 171.4 212.4 275.4
Rated Voltage
Rated Frequency
Three-Phase 208 Vac 50/60 Hz
Allowable Voltage
Fluctuation
-15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
88
*3
114
*3
143
*3
169
*3
211
*3
273
*3
Minimum Applicable
Motor Current (A)
15 15 30 30 30 45
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage
(V)
Three-Phase 208 Vac
Maximum Output
Frequency (Hz)
240 Hz
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
