YASKAWA HV600 User Manual

7.5 240 V Enclosed Model Specifications
536 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Model A022 A028 A042 A054 A068 A080
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
Table 7.10 240 V Enclosed Ratings
Model
A104 A130 A154 A192 A248
Maximum Applicable Motor Output (HP)
*2
40 50 60 75 100
Input
Rated Input Current (A) 106.1 132.1 156.1 193.3 250.1
Rated Voltage
Rated Frequency
Three-Phase 208 Vac 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
104
*3
130
*3
154
*3
192
*3
248
*3
Minimum Applicable Motor
Current (A)
15 30 30 30 45
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage (V) Three-Phase 208 Vac
Maximum Output Frequency
(Hz)
240 Hz
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
