YASKAWA HV600 User Manual

7.6 480 V Enclosed Model Specifications
538 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Model B021 B027 B034 B040 B052 B065 B077
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
Table 7.13 480 V Enclosed Ratings
Model B096 B124 B156 B180 B240 B302
Maximum Applicable Motor Output (HP)
*2
75 100 125 150 200 250
Input
Rated Input Current (A) 97.0 125.0 157.0 180.6 241.0 303.0
Rated Voltage
Rated Frequency
Three-Phase 480 Vac 50/60 Hz
Allowable Voltage
Fluctuation
-15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
96
*3
124
*3
156
*3
180
*3
240
*3
302
*3
Minimum Applicable Motor
Current (A)
15 15 30 30 30 45
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage (V) Three-Phase 480 Vac
Maximum Output Frequency
(Hz)
240 Hz
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
