Periodic Inspection and Maintenance
8
8.4 Replace Drive Cooling Fans and Circulation Fans
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 571
2. Put the side of the fan nearest to the top of the drive in first, and push it until the tabs click into position.
A - Circulation fan B - Tabs
Figure 8.24 Install the Circulation Fan
3. Connect the power supply connector.
Figure 8.25 Connect the Power Supply Connector
