YASKAWA HV600 User Manual

9.4 A: Initialization Parameters
596 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
No.
(Hex.)
Name Description
Default
(Range)
Ref.
A2-06
(010B)
User Parameter 6 Sets the parameter number to be shown for number 6 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
C1-02
(A1-00 - Z3-16)
186
A2-07
(010C)
User Parameter 7 Sets the parameter number to be shown for number 7 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
C6-02
(A1-00 - Z3-16)
186
A2-08
(010D)
User Parameter 8 Sets the parameter number to be shown for number 8 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-01
(A1-00 - Z3-16)
186
A2-09
(010E)
User Parameter 9 Sets the parameter number to be shown for number 9 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-02
(A1-00 - Z3-16)
186
A2-10
(010F)
User Parameter 10 Sets the parameter number to be shown for number 10 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-03
(A1-00 - Z3-16)
186
A2-11
(0110)
User Parameter 11 Sets the parameter number to be shown for number 11 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-04
(A1-00 - Z3-16)
186
A2-12
(0111)
User Parameter 12 Sets the parameter number to be shown for number 12 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-17
(A1-00 - Z3-16)
186
A2-13
(0112)
User Parameter 13 Sets the parameter number to be shown for number 13 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
E1-01
(A1-00 - Z3-16)
186
A2-14
(0113)
User Parameter 14 Sets the parameter number to be shown for number 14 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
E1-03
(A1-00 - Z3-16)
186
A2-15
(0114)
User Parameter 15 Sets the parameter number to be shown for number 15 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
E1-04
(A1-00 - Z3-16)
186
A2-16
(0115)
User Parameter 16 Sets the parameter number to be shown for number 16 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
E1-05
(A1-00 - Z3-16)
186
A2-17
(0116)
User Parameter 17 Sets the parameter number to be shown for number 17 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E1-06
(A1-00 - Z3-16)
186
A2-18
(0117)
User Parameter 18 Sets the parameter number to be shown for number 18 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E1-09
(A1-00 - Z3-16)
186
A2-19
(0118)
User Parameter 19 Sets the parameter number to be shown for number 19 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E1-13
(A1-00 - Z3-16)
186
A2-20
(0119)
User Parameter 20 Sets the parameter number to be shown for number 20 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E2-01
(A1-00 - Z3-16)
186
A2-21
(011A)
User Parameter 21 Sets the parameter number to be shown for number 21 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E2-04
(A1-00 - Z3-16)
186
A2-22
(011B)
User Parameter 22 Sets the parameter number to be shown for number 22 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E2-11
(A1-00 - Z3-16)
186
A2-23
(011C)
User Parameter 23 Sets the parameter number to be shown for number 23 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
H4-02
(A1-00 - Z3-16)
186
A2-24
(011D)
User Parameter 24 Sets the parameter number to be shown for number 24 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
L1-01
(A1-00 - Z3-16)
186
A2-25
(011E)
User Parameter 25 Sets the parameter number to be shown for number 25 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
L3-04
(A1-00 - Z3-16)
186
