YASKAWA HV600 User Manual

Parameter List
9
9.4 A: Initialization Parameters
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 597
No.
(Hex.)
Name Description
Default
(Range)
Ref.
A2-26
(011F)
User Parameter 26 Sets the parameter number to be shown for number 26 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(A1-00 - Z3-16)
186
A2-27
(0120)
User Parameter 27 Sets the parameter number to be shown for number 27 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(A1-00 - Z3-16)
186
A2-28
(0121)
User Parameter 28 Sets the parameter number to be shown for number 28 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(A1-00 - Z3-16)
186
A2-29
(0122)
User Parameter 29 Sets the parameter number to be shown for number 29 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(A1-00 - Z3-16)
186
A2-30
(0123)
User Parameter 30 Sets the parameter number to be shown for number 30 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(A1-00 - Z3-16)
186
A2-31
(0124)
User Parameter 31 Sets the parameter number to be shown for number 31 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(A1-00 - Z3-16)
186
A2-32
(0125)
User Parameter 32 Sets the parameter number to be shown for number 32 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(A1-00 - Z3-16)
186
A2-33
(0126)
User Parameter Auto
Selection
Sets the automatic save feature for changes to parameters A2-17 to A2-32 [User
Parameters 17 to 32].
0 : Disabled: Manual Entry Required
1 : Enabled: Auto Save Recent Parms
Determined by A1-06
(0, 1)
186
