Parameter List
9
9.10 H: Terminal Functions
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 629
Setting Value Function Description Ref.
2D Differential Level Source Enters a feedback value to calculate the Differential Level between the Differential Level Source feedback and the
primary PID Feedback [H3-xx = B].
Note:
The full-scale of the analog signal goes from b5-71 [Min PID Transducer Scaling] to b5-38 [PID User Unit
Display Scaling].
302
2E HAND Frequency Ref or
Setpoint
Enters the S5-05 [HAND Frequency Reference] value or the S5-06 [HAND Setpoint] value. When S5-01 = 0 [HAND
Frequency Reference Source = HAND Analog Input] and S5-03 = 0 [HAND Mode PI Selection = Disabled], the drive
enters HAND Frequency Reference. When b5-01 ≠0, S5-01 = 0, and S5-03 = 1 [Enabled], the drive enters HAND
Setpoint.
Note:
• When PID is enabled, the full-scale of the analog signal goes from b5-71 [Min PID Transducer Scaling] to b5-38
[PID User Unit Display Scaling].
• When PID is disabled, the drive enters this analog signal as the percentage of the E1-04 [Maximum Output
Frequency] value.
303
â—† H4: Analog Outputs
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H4-01
(041D)
Terminal FM Analog
Output Select
Sets the monitor number to send from MFAO terminal FM.
Set the x-xx part of the Ux-xx [Monitor]. For example, set H4-01 = 102 to monitor U1-02
[Output Frequency].
102
(000 - 999)
304
H4-02
(041E)
RUN
Terminal FM Analog
Output Gain
Sets the gain of the monitor signal that is sent from MFAO terminal FM.
Sets the analog signal output level from the terminal FM at 10 Vor 20 mA as 100% when
an output for monitoring items is 100%.
100.0%
(-999.9 - +999.9%)
304
H4-03
(041F)
RUN
Terminal FM Analog
Output Bias
Sets the bias of the monitor signal that is sent from MFAO terminal FM.
Set the level of the analog signal sent from terminal FM at 10 V or 20 mA as 100% when
an output for monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
305
H4-04
(0420)
Terminal AM Analog
Output Select
Sets the monitoring number to be output from the MFAO terminal AM.
Set the x-xx part of the Ux-xx [Monitor]. For example, set H4-04 = 103 to monitor U1-03
[Output Current].
103
(000 - 999)
305
H4-05
(0421)
RUN
Terminal AM Analog
Output Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AM.
When an output for monitoring items is 0%, this parameter sets the analog signal output
level from the AM terminal at 10 Vor 20 mA as 100%.
50.0%
(-999.9 - +999.9%)
305
H4-06
(0422)
RUN
Terminal AM Analog
Output Bias
Sets the bias of the monitor signal that is sent from MFAO terminal AM.
When an output for monitoring items is 0%, this parameter sets the analog signal output
level from the AM terminal at 10 Vor 20 mA as 0%.
0.0%
(-999.9 - +999.9%)
305
H4-07
(0423)
Terminal FM Signal
Level Select
Sets the MFAO terminal FM output signal level.
Note:
Set jumper S5 on the control circuit terminal block accordingly when you change this
parameter.
0 : 0 to 10 Vdc
2 : 4 to 20 mA
0
(0, 2)
305
H4-08
(0424)
Terminal AM Signal
Level Select
Sets the MFAO terminal AM output signal level.
Note:
Set jumper S5 on the control circuit terminal block accordingly when you change this
parameter.
0 : 0 to 10 Vdc
2 : 4 to 20 mA
0
(0, 2)
306
H4-20
(0B53)
Analog Power Monitor
100% Level
Sets the level at 10 V when you set U1-08 [Output Power] for analog output. 0.00 kW
(0.00 - 650.00 kW)
306
