YASKAWA HV600 User Manual

Parameter List
9
9.16 Y: Application Features
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 661
No.
(Hex.)
Name Description
Default
(Range)
Ref.
Y4-42
(3D23)
Output Disconnect
Detection Sel
This parameter applies only when in Drive Mode. It sets the drive response if the
connection between the drive and the motor is disconnected.
0 : Disabled
1 : Alarm - Speed Search
2 : Alarm - Start at Zero
3 : Fault
Note:
1. Loss Of Load [Z1-31 to Z1-36], Load Verify [Z1-53], and Bypass Energy Savings
[Z1-16] can interfere with the correct operation of Output Disconnect Detection.
2. When the Output Disconnect is active, the drive internally disables Output Phase
Loss Detection of more than one phase.
0
(0 - 3)
419
Y4-43
(3D24)
Output Disconnect Inject
Current
Sets the level of DC injection current during output disconnect as a percentage of the drive
rated current.
30%
(5 - 50%)
419
◆ YA: Preset Setpoint
No.
(Hex.)
Name Description
Default
(Range)
Ref.
YA-01
(3E58)
RUN
Setpoint 1 Sets the PID Setpoint when b1-01 = 0 [Frequency Reference Selection 1 = Keypad or
Multi-Speed Selection].
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display
Scaling], and b5-39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.00
(0.00 - 600.00)
420
YA-02
(3E59)
RUN
Setpoint 2 Sets the PID Setpoint as specified by the Multi-Setpoint digital inputs.
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display
Scaling], and b5-39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.00
(0.00 - 600.00)
420
YA-03
(3E5A)
RUN
Setpoint 3 Sets the PID Setpoint as specified by the Multi-Setpoint digital inputs.
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display
Scaling], and b5-39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.00
(0.00 - 600.00)
421
YA-04
(3E5B)
RUN
Setpoint 4 Sets the PID Setpoint as specified by the Multi-Setpoint digital inputs.
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display
Scaling], and b5-39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.00
(0.00 - 600.00)
421
◆ YC: Foldback Features
No.
(Hex.)
Name Description
Default
(Range)
Ref.
YC-01
(3EBC)
Output Current Limit
Select
Sets the function to enable or disable the output current regulator.
0 : Disabled
1 : Enabled
0
(0, 1)
421
YC-02
(3EBD)
RUN
Current Limit Sets the current limit.
Note:
Value is internally limited to 300% of the drive rated current set in n9-01 [Inverter
Rated Current].
0.0 A
(0.0 - 1000.0 A)
421
◆ YF: PI Auxiliary Control
No.
(Hex.)
Name Description
Default
(Range)
Ref.
YF-01
(3F50)
PI Aux Control Selection Sets the PI Auxiliary Control function.
0 : Disabled
1 : Enabled
0
(0, 1)
423
YF-02
(3F51)
RUN
PI Aux Control
Transducer Scale
Sets the full scale (10 Vor 20 mA) output of the pressure transducer connected to the
analog input terminal programmed for H3-xx = 27 [PI Aux Control Feedback Level].
Note:
Parameters YF-21 [PI Aux Ctrl Level Unit Selection] and YF-22 [PI Aux Level
Decimal Place Pos] set the unit and resolution.
145.0
(1.0 - 6000.0)
423
