YASKAWA HV600

Parameter List
9
9.18 U: Monitors
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 683
No.
(Hex.)
Name Description MFAO Signal Level
U6-83
(07B3)
Option IP Address 4 Shows the currently available local IP Address (4th octet). No signal output available
U6-84
(07B4)
Online Subnet 1 Shows the currently available subnet mask (1st octet). No signal output available
U6-85
(07B5)
Online Subnet 2 Shows the currently available subnet mask (2nd octet). No signal output available
U6-86
(07B6)
Online Subnet 3 Shows the currently available subnet mask (3rd octet). No signal output available
U6-87
(07B7)
Online Subnet 4 Shows the currently available subnet mask (4th octet). No signal output available
U6-88
(07B8)
Online Gateway 1 Shows the currently available Gateway address (1st octet). No signal output available
U6-89
(07B9)
Online Gateway 2 Shows the currently available Gateway address (2nd octet). No signal output available
U6-90
(07F0)
Online Gateway 3 Shows the currently available Gateway address (3rd octet). No signal output available
U6-91
(07F1)
Online Gateway 4 Shows the currently available Gateway address (4th octet). No signal output available
U6-92
(07F2)
Online Speed Shows the currently available communications speed.
10: 10 Mbps
100: 100 Mbps
No signal output available
U6-93
(07F3)
Online Duplex Shows the currently available Duplex setting. No signal output available
U6-98
(07F8)
First Fault Shows the contents of the most recent communication options fault (Modbus TCP/IP, EtherNet/IP). No signal output available
U6-99
(07F9)
Current Fault Shows the contents of current fault from communication options (Modbus TCP/IP, EtherNet/IP). No signal output available
◆ Ub: Bypass Control Monitors
No.
(Hex.)
Name Description MFAO Signal Level
Ub-01
(8780)
Motor Current Format is XXX.X amps. The number of decimal places depends on drive kVA rating.
Unit: Amp
No signal output available
Ub-02
(8781)
Bypass Digital Input Status View status of bypass digital inputs XXXXXXXX
Where X = 0 (not asserted) or 1 (asserted) The right-most digit is the status of digital input 1.
This monitor will show the digital input status and any digital input forced to “ON” over serial
communications.
Unit: -
No signal output available
Ub-03
(8782)
Bypass Digital Output Status View status of bypass digital outputs XXXXXXXX
Where X = 0 (not asserted) or 1 (asserted) The right-most digit is the status of digital input 1.
Unit: -
No signal output available
Ub-04
(8783)
Bypass Dig Out Status D09/
D10
View status of bypass digital outputs XXXXXXXX
Where X = 0 (not asserted) or 1 (asserted) The right-most digit is the status of digital input 9.
Unit: -
No signal output available
