9.18 U: Monitors
682 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
No.
(Hex.)
Name Description MFAO Signal Level
U5-30
(3000)
Time Hr Min HHMM Shows the current time (Hours and Minutes). No signal output available
U5-31
(3001)
Date Year Shows the current year. No signal output available
U5-32
(3002)
Date Mo Day MMDD Shows the current date (Month and Date). No signal output available
U5-33
(3003)
Date Week Shows the current date of the week.
bit 0 : Sunday
bit 1 : Monday
bit 2 : Tuesday
bit 3 : Wednesday
bit 4 : Thursday
bit 5 : Friday
bit 6 : Saturday
bit 7 : Not used (normal value of 0).
No signal output available
U5-79
(3B9A)
PID Feedback Backup Shows the PID Feedback Backup [H3-xx = 24] signal that the drive uses when it loses the PID
Feedback [H3-xx = B].
Unit: 0.01%
Note:
Display unit and scaling are dependent on System Units.
No signal output available
U5-81
(3B9C)
Diff Level Source Shows the Differential Feedback signal from the terminal set for H3-xx = 2D [Differential Level
Source].
Unit: 0.00%
Note:
Unit and display scaling are dependent on System Units.
No signal output available
U5-99
(1599)
Setpoint Shows the PID setpoint command.
Unit: 0.01%
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display Scaling], and b5-
39 [PID User Unit Display Digits] set the unit, range, and resolution.
10 V = Maximum frequency
(-10 V to +10 V)
â—† U6: Operation Status Monitors
No.
(Hex.)
Name Description MFAO Signal Level
U6-01
(0051)
Iq Secondary Current Shows the value calculated for the motor secondary current (q-Axis) as a percentage of the motor
rated secondary current.
Unit: 0.1%
10 V: Motor secondary rated
current (0 V to +10 V)
U6-17
(07D1)
Expert
Energy Save Coeff Shows the total time of direction of motor rotation detections for Speed Estimation Speed Searches.
This value adjusts b3-26 [Direction Determination Level].
Note:
Upper limit is +32767 and lower limit is -32767.
No signal output available
U6-21
(07D5)
Offset Frequency Shows the total value of d7-01 to d7-03 [Offset Frequency 1 to 3] selected with Add Offset
Frequency 1 to 3 [H1-xx = 44 to 46].
Unit: 0.1%
10 V: Maximum Frequency
U6-31
(007B)
TorqueDetect Monitor Monitors the torque reference or the output current after applying the filter.
Unit: 0.1%
10 V:100%
U6-36
(0720)
Expert
Comm Errors-Host Shows the number of inter-CPU communication errors. When you de-energize the drive, this value
resets to 0.
No signal output available
U6-37
(0721)
Expert
Comm Errors-Sensor Shows the number of inter-CPU communication errors. When you de-energize the drive, this value
resets to 0.
No signal output available
U6-80
(07B0)
Option IP Address 1 Shows the currently available local IP Address (1st octet). No signal output available
U6-81
(07B1)
Option IP Address 2 Shows the currently available local IP Address (2nd octet). No signal output available
U6-82
(07B2)
Option IP Address 3 Shows the currently available local IP Address (3rd octet). No signal output available
