Parameter List
9
9.19 Defaults by Bypass and Drive Model
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 689
No. Name Unit Default
-
Bypass
Model
-
D002
D003
D004
D007
D010
A002
A003
A004
A006
A009
D016
A015
D024
A022
D030
A028
D046
A042
D059
A054
D074
A068
D088
A080
o2-04
Drive
Model
(KVA)
Selection
Hex. 65 67 68 6A 6B 6D 6E 6F
E2-11
Motor
Rated
Power
HP
(kW)
3
(2.2)
5
(3.7)
7.5
(5.5)
10
(7.5)
15
(11)
20
(15)
25
(18.5)
30
(22)
L2-04
Powerloss V/
f Recovery
Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.6 0.6 0.6
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 190 190 190 190 190 190 190 190
L3-24
Motor Accel
Time for
Inertia Cal
s 0.145 0.154 0.168 0.175 0.265 0.244 0.317 0.355
L8-02
Overheat
Alarm Level
°C 95 95 125 125 125 125 115 115
L8-09
Output
Ground Fault
Detection
- 0 0 0 0 0 1 1 1
L8-35
Installation
Method
Selection
- 2 2 2 2 2 2 2 2
L8-38
Carrier
Frequency
Reduction
- 2 2 2 2 2 2 2 2
n1-01
Hunting
Prevention
Selection
- 1 1 1 1 1 1 1 1
n1-03
Hunting
Prevention
Time
Constant
ms 10 10 10 10 10 10 10 10
No. Name Unit Default
- Drive Model -
D114
A104
D143
A130
D169
A154
D211
A192
D273
A248
o2-04
Drive Model (KVA)
Selection
Hex. 70 72 73 74 75
E2-11
Motor Rated
Power
HP
(kW)
40
(30)
50
(37)
60
(45)
75
(55)
100
(75)
b3-04
V/f Gain during
Speed Search
% 80 80 80 80 80
b3-06
Speed Estimation
Current Level 1
- 0.5 0.5 0.5 0.5 0.7
b3-08
Speed Estimation
ACR P Gain
- 0.50 0.50 0.50 0.50 0.50
b3-11
Spd Est Method
Switch-over Level
% 5.0 5.0 5.0 5.0 5.0
b3-12
Speed Search
Current Deadband
- 2.5 2.5 2.5 2.5 2.5
b3-26
Direction
Determination Level
- 1000 1000 1000 1000 1000
b8-04
Energy Saving
Coefficient Value
- 46.27 38.16 35.78 31.35 23.10
C6-02
Carrier Frequency
Selection
- 2 2 2 2 2
E2-01
Motor Rated Current
(FLA)
A 114 143 169 211 273
