10.3 BACnet Communications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 707
Object ID
Object Name
(Network Display, if
Different)
Modbus Reg. Active Text Inactive Text PV Access
BI4
Drive Input Terminal 4
(Input Terminal 4)
002Bh:bit 3 ON OFF R
BI5
Drive Input Terminal 5
(Input Terminal 5)
002Bh:bit 4 ON OFF R
BI6
Drive Input Terminal 6
(Input Terminal 6)
002Bh:bit 5 ON OFF R
BI7
Drive Input Terminal 7
(Input Terminal 7)
002Bh:bit 6 ON OFF R
BI8
Drive MF Output 1
(Multi Function Out 1)
0020h:bit 5 ON OFF R
BI9
Drive MF Output 2
(Multi Function Out 2)
0020h:bit 6 ON OFF R
BI10 BYP DI-1 STAT 8781h:bit 0 ON OFF R
BI11 BYP DI-2 STAT 8781h:bit 1 ON OFF R
BI12 BYP DI-3 STAT 8781h:bit 2 ON OFF R
BI13 BYP DI-4 STAT 8781h:bit 3 ON OFF R
BI14 BYP DI-5 STAT 8781h:bit 4 ON OFF R
BI15 BYP DI-6 STAT 8781h:bit 5 ON OFF R
BI16 BYP DI-7 STAT 8781h:bit 6 ON OFF R
BI17 BYP DI-8 STAT 8781h:bit 7 ON OFF R
BI18 BYP DO-1 STAT 8782h:bit 0 ON OFF R
BI19 BYP DO-2 STAT 8782h:bit 1 ON OFF R
BI20 BYP DO-3 STAT 8782h:bit 2 ON OFF R
BI21 BYP DO-4 STAT 8782h:bit 3 ON OFF R
BI22 BYP DO-5 STAT 8782h:bit 4 ON OFF R
BI23 BYP DO-6 STAT 8782h:bit 5 ON OFF R
BI24 BYP DO-7 STAT 8782h:bit 6 ON OFF R
BI25 BYP DO-8 STAT 8782h:bit 7 ON OFF R
BI26 BYP DO-9 STAT 8783h:bit 0 ON OFF R
BI27 BYP DO-10 STAT 8783h:bit 1 ON OFF R
BI28 Drive Fault Status 004Bh:bit 7 ON OFF R
BI29 Drive Alarm Status 004Bh:bit 6 ON OFF R
BI30 Sys Alarm Status 8784h:bit 8 ON OFF R
■ Binary Output Objects
Object ID Object Name Modbus Reg. Active Text Inactive Text PV Access
BO1 MF Output M1 - M2 0009h: Bit 0 ON OFF C
BO2 MF Output M3 - M4 0009h: Bit 1 ON OFF C
BO3 MF Output M5 – M6 0009h: Bit 2 ON OFF C
BO4 Ref Sel:PI Setpoint 000Fh: Bit 1 ON OFF C
BO5 Ref Sel:Term S5 IN 0001h: Bit 8 ON OFF C
BO6 Ref Sel:Term S6 IN 0001h: Bit 9 ON OFF C
BO7 Ref Sel:Term S7 IN 0001h: Bit A ON OFF C
BO8 BYP DO-07 COMMAND 8403h: Bit 6 ON OFF C
