10.3 BACnet Communications
708 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Object ID Object Name Modbus Reg. Active Text Inactive Text PV Access
BO9 BYP DO-08 COMMAND 8403h: Bit 7 ON OFF C
BO10 BYP DO-09 COMMAND 8403h: Bit 8 ON OFF C
BO11 BYP DO-10 COMMAND 8403h: Bit 9 ON OFF C
■ Binary Value Objects
Object ID
Object Name
(Network Display, if
Different)
Modbus Reg. Active Text Inactive Text PV Access
BV1 Not Used BV001 - - - C
BV2 Not Used BV002 - - - C
BV3
Drive External Fault
Command
(Ext Fault Cmd)
0001h: Bit 2 FAULT OFF C
BV4
Drive Fault Reset Command
(Fault Reset Cmd)
0001h: Bit 3 RESET OFF C
BV5 Not Used BV005 - - - C
BV6 Not Used BV006 - - - C
BV7
Drive Multi-Function Input 3
Command
(MF Input 3 Cmd)
0001h: Bit 6 ON OFF C
BV8
Drive Multi-Function Input 4
Command
(MF Input 4 Cmd)
0001h: Bit 7 ON OFF C
BV9
Drive Multi-Function Input 5
Command
(MF Input 5 Cmd)
0001h: Bit 8 ON OFF C
BV10
Drive Multi-Function Input 6
Command
(MF Input 6 Cmd)
0001h: Bit 9 ON OFF C
BV11
Drive Multi-Function Input 7
Command
(MF Input 7 Cmd)
0001h: Bit A ON OFF C
BV12
Set Fault Contact Cmd
(Set Flt Contact Cmd)
0009h: Bit 6&7 ENABLE OFF C
BV13 RUN-STOP 0020h: Bit 0 RUN OFF R
BV14 REV-FWD 0020h: Bit 1 REV FWD R
BV15 READY 0020h: Bit 2 READY OFF R
BV16 FAULT 0020h: Bit 3 FAULTED OFF R
BV17 Data Set Error 0020h: Bit 4 ERR OFF R
BV18
Overcurrent – Ground Fault
( Overcurrent– Gnd Fault)
0021h: Bit 0 OC – GF OFF R
BV19
Main Circuit Overvoltage
(Main Ckt Overvoltage)
0021h: Bit 1 OV OFF R
BV20 Drive Overload 0021h: Bit 2 OL2 OFF R
BV21 Drive Overheat 0021h: Bit 3 OH1-OH2 OFF R
BV22 Fuse Blown 0021h: Bit 5 PUF OFF R
BV23 PI Feedback Loss 0021h: Bit 6 FBL OFF R
BV24 External Fault 0021h: Bit 7 EF0 – EF OFF R
BV25 Hardware Error 0021h: Bit 8 CPF OFF R
BV26
Motor Overload –
Overtorque
(Mtr OvrLd – OvrTorque)
0021h: Bit 9 OL1 – OL3 OFF R
To Next Page
