10.5 Metasys N2 Communications
734 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
â– Metasys N2 Analog Input (AI) Summary
Table 10.15 Metasys N2 Analog Input Summary (Drive to Metasys N2)
Object ID Object Name Units Drive Parameters
AI 1 Speed Reference 0.01 Hz U1-01
AI 2 Output Speed 0.01 Hz U1-02
AI 3 Output Current 0.1 A UB-01
AI 4 kWatt Hour Meter kWh U4-10
AI 5 Output Power 0.1 kWh U1-08
AI 6 Drive Temperature 1 °C U4-08
AI 7 PI Feedback 0.01% U5-01
AI 8 AC Output Voltage 0.1 Vac U1-06
AI 9 DC Bus Voltage 1 Vdc U1-07
AI 10 Fault Code - U2-01
AI 11 Elapsed Time - Hours 1 hour U4-01
AI 12 Elapsed Time - 10K Hours 10K hours U4-01
AI 13 MWatt Hour meter MWh U4-11
AI 14 Drive Rated Current A -
AI 15 Communication Error Code - U1-19
AI 16 PI Deviation 0.01% U5-02
AI 17 PI Output Capacity 0.01% U5-03
AI 18 PI Reference 0.01% U5-04
AI 19
*1
Last Fault Code - U2-02
AI 20 Freq Ref @ Fault 0.01 Hz U2-03
AI 21 Output Freq @ Fault 0.01 Hz U2-04
AI 22 Output Current @ Fault 0.1 A U2-05
AI 23 Out Volt Ref @ Fault 0.1 Vac U2-07
AI 24 DC Bus Volts @ Fault 1 Vdc U2-08
AI 25 Output Power @ Fault 0.1 kW U2-09
AI 26 Byp Input Terminal Status @ Fault - U2-11
AI 27 Byp Output Terminal Status @ Fault - U2-12
AI 28 Bypass Operation Status @ Fault - U2-13
AI 29 Elapsed Operation Time @ Fault 1 hour U2-14
AI 30
*1
Most Recent Fault - U3-01
AI 31
*1
2nd Most Recent Fault - U3-02
AI 32
*1
3rd Most Recent Fault - U3-03
AI 33
*1
4th Most Recent Fault - U3-04
AI 34 Elapsed Time @ Current Fault 1 hour U3-11
AI 35 Elapsed Time @ 2nd Fault 1 hour U3-12
AI 36 Elapsed Time @ 3rd Fault 1 hour U3-13
AI 37 Elapsed Time @ 4th Fault 1 hour U3-14
AI 38 Read Parameter Data - -
