Network Communications
10
10.5 Metasys N2 Communications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 735
*1 Refer to Faults, Minor Faults, Alarms, and Error Codes Listed by Decimal Value for Use with BACnet/Modbus on page 466 for
information on fault decimal values.
■ Metasys N2 Analog Output (AO) Summary
Table 10.16 Metasys N2 Analog Output Summary (Drive to Metasys N2)
Object ID Object Name Units Default Value Drive Parameters
AO 1 Speed Command 0.01 Hz - -
AO 2 Acceleration Time s 30.0 C1-01
AO 3 Deceleration Time s 30.0 C1-02
AO 4 PI Proportional Gain - 2.00 b5-02
AO 5 PI Integral Time s 5.0 b5-03
AO 6 Stall Prevention Level - Run % 120 L3-06
AO 7 Stall Prevention Level - Accel % 120 L3-02
AO 8 Reference Operation Mode Select - 1 b1-01
AO 9 Run Operation Mode Select - 1 b1-02
AO 10 PI Mode Select - 0 b5-01
AO 11 Frequency Command Upper Limit % of Max 100.0 d2-01
AO 12 Frequency Command Lower Limit % of Max 0.0 d2-02
AO 13 Motor Rated Current A Motor model dependent E2-01
AO 14 Jump Frequency 1 0.1 Hz 0.0 d3-01
AO 15 Jump Frequency 2 0.1 Hz 0.0 d3-02
AO 16 Jump Frequency 3 0.1 Hz 0.0 d3-03
AO 17 Jump Frequency Bandwidth 0.1 Hz 1.0 d3-04
AO 18 Number of Auto Restarts - 0 L5-01
AO 19 Operator Display Mode - 0 o1-03
AO 20 Power Loss Ride-Thru s Drive model dependent L2-02
AO 21 Cable Loss Timeout s 2.0 H5-09
AO 22 Cable Loss Speed 0.01 Hz 0.00 H5-34
AO 23 PI Integral Limit 0.1% 100.0 b5-04
AO 24 PI Upper Limit Value 0.1 100.0 b5-06
AO 25 PI Offset Adjustment 0.1 0.0 b5-07
AO 26 PI Primary Delay Time 0.01 0.00 b5-08
AO 27 Not Used - - -
AO 28 Not Used - - -
AO 29 Not Used - - -
AO 30 Read Parameter Number - - -
AO 31 Write Parameter Number - - -
AO 32 Write Parameter Data - - -
■ Metasys N2 Binary Input (BI) Summary
Table 10.17 Metasys N2 Binary Input Summary (Drive to Metasys N2)
Object ID Object Name Default OFF (0) State ON (1) State
BI 1 System Run/Stop Monitor 0 Stopped Running
BI 2 System Forward/Reverse Monitor 0 Forward Reverse
BI 3 System Ready Monitor 0 Not Ready Ready
