YASKAWA HV600 User Manual

Electrical Installation
3
3.3 Main Circuit Wiring
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 85
■ 240 V Enclosed Wire Gauges and Torques
Table 3.7 Input Wiring
Model
H6BP
Standard Non-Fused
Input Disconnect Switch S1
With Option PM
Circuit Breaker CB1
Current Rating
Amps
AWG, kcmil
Tightening Torque
(in lb)
Current Rating
Amps
AWG, kcmil
Tightening Torque
(in lb)
A002 20 14-8 20 15 14-10 or 8-3/0 50 or 120
A003
20 14-8 20 15 14-10 or 8-3/0 50 or 120
A004
20 14-8 20 15 14-10 or 8-3/0 50 or 120
A006
20 14-8 20 20 14-10 or 8-3/0 50 or 120
A009 20 14-8 20 25 14-10 or 8-3/0 50 or 120
A015
20 14-8 20 35 14-10 or 8-3/0 50 or 120
A022
45 10, 8, or (6-2) 35, 40, or 50 50 14-10 or 8-3/0 50 or 120
A028
63 10, 8, or (6-2) 35, 40, or 50 70 14-10 or 8-3/0 50 or 120
A042
100 8-2/0 200 100 14-10 or 8-3/0 50 or 120
A054
100 8-2/0 200 125 14-10 or 8-3/0 50 or 120
A068
100 8-2/0 200 150 14-10 or 8-3/0 50 or 120
A080
115 8-2/0 200 150 14-10 or 8-3/0 50 or 120
A104
175 4-4/0 225 150 14-10 or 8-3/0 50 or 120
A130
250 3/0-350 kcmil 225 250 4-4/0 225
A154
250 3/0-350 kcmil 225 250 3/0-350 225
A192
250 3/0-350 kcmil 225 400 (1-2) x (2/0-500 kcmil) (1-2) x 442
A248
400 (1-2) x (2/0-500 kcmil) (1-2) x 442 600 (1-2) x (2/0-500 kcmil) (1-2) x 442
Table 3.8 Output and Control Wiring
Model
H6BP
Motor Wiring
Standard Motor
Terminal Block TB1
Ground Wiring
Control Wiring
AWG,
kcmil
Tightening
Torque
(in lb)
AWG,
kcmil
Tightening
Torque
(in lb)
A1
Terminal Blocks
TB1, TB3-TB6
A1
Terminal Block
TB2 (FE)
A2
Terminal Blocks
TB1-TB4 and TB6
Panel
Terminal Block
TB4
AWG,
kcmil
Tightening
Torque
(in lb)
AWG,
kcmil
Tightening
Torque
(in lb)
AWG,
kcmil
Tightening
Torque
(in lb)
AWG,
kcmil
Tightening
Torque
(in lb)
A002 14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A003
14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A004
14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A006
14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A009 14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A015
14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A022
14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A028
14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A042
14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
A054
14-2 32
14-10, 8, 6-
4, or 2
35, 40, 45,
or 50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
