YASKAWA P1000 User Manual

IP20/NEMA Type 1 Kit Selection
Customers may convert IP00/Open Type models to IP20/NEMA Type 1 enclosures. Refer to Table 2.9 to select the appropriate
IP20/NEMA Type 1 Kit when performing the conversion.
Contact a Yaskawa representative for IP20/NEMA Type 1 Kit availability for IP00/Open Type models not listed.
Table 2.9 IP20/NEMA Type 1 Kit Selection
IP00/Open Type
Drive Model
IP20/NEMA Type 1 Kit Code Comments
2A0250A
100-054-503
Refer to IP20/NEMA Type 1 Enclosure
Drives on page 31 for drive dimensions with the
IP20/NEMA Type 1 Kit installed.
2A0312A
2A0360A
4A0208A
4A0250A
100-054-5044A0296A
4A0362A
5A0125A
100-054-503
5A0145A
5A0192A
100-054-504
5A0242A
2.1 Mechanical Installation
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
39
2
Mechanical Installation

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
