Yealink SIP-T38G Administrator's Guide

Configuring Advanced Features
145
<YealinkIPPhoneText>
If the recording fails for some reasons, for example, the recording box is full, the server
will respond with 200 OK as below:
<YealinkIPPhoneText>
<Title>
</Title>
<Text>
Probably the recording box is full.
</Text>
<YealinkIPPhoneText>
When the user presses the URL record key for the second time, the IP phone sends an
HTTP GET message to the server, and then the server will respond with the following 200
OK message:
<YealinkIPPhoneText>
<Title>
</Title>
<Text>
The recording session is successfully stopped.
</Text>
<YealinkIPPhoneText>
Procedure
Call recording key can be configured using the configuration files or locally.
Configuration File
<y0000000000xx>.cfg
Assign a record key.
For more information, refer to
Record Key on page 331.
Assign a URL record key.
For more information, refer to URL
Record Key on page 332.
Local
Web User Interface
Assign a record key.
Assign a URL record key.
Navigate to:
http://<phoneIPAddress>/cgi-bin/
cgiServer.exx?page=Dsskey.htm
Phone User Interface
Assign a record key.
Assign a URL record key.
To configure a Record key via web user interface:
1. Click on DSS Key->Memory Key (or Line Key).

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
