Yealink SIP-T38G Administrator's Guide

Getting Started
21
PPPoE (Point-to-Point Protocol over Ethernet) is a network protocol that is used by Internet
Service Providers (ISPs) to provision Digital Subscriber Line (DSL) high speed Internet
services. PPPoE allows an office or building-full of users to share a common DSL
connection to the Internet. The Internet port on the IP phone can be configured as a
PPPoE port to connect to the Internet. Contact your ISP for the PPPoE username and
password.
Procedure
PPPoE can be configured using the configuration files or locally.
Configuration File
<y0000000000xx>.cfg
Configure PPPoE on the IP phone.
For more information, refer to
PPPoE on page 227.
Local
Web User Interface
Configure PPPoE on the IP phone.
Navigate to:
http://<phoneIPAddress>/cgi-bin/
cgiServer.exx?page=Network-B
asic.htm
Phone User Interface
Configure PPPoE on the IP phone.
To configure PPPoE via web user interface:
1. Click on Network->Basic.
2. In the Internet Port field, mark the PPPoE radio box.

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
