Yealink SIP-T38G Administrator's Guide

Appendix
367
The following figure illustrates successful call forwarding between Yealink SIP IP phones
in which User B has enabled always call forward. The incoming call is immediately
forwarded to User C when User A calls User B. In this call flow scenario, the end users
are User A, User B, and User C. They are all using Yealink SIP IP phones, which are
connected via an IP network.
The call flow scenario is as follows:
1. User B enables always call forward, and the destination number is User C.
2. User A calls User B.
3. User B forwards the incoming call to User C.
4. User C answers the call.
Call is established between User A and User C.
User A Proxy Server User B User C
F1. INVITE B
F2. INVITE B
F3. 302 Move Temporarily
F6. ACK
F7. INVITE C
F8. INVITE C
F9. 180 Ringing
F10. 180 Ringing
F11. 200 OK
F12. 200 OK
F13. ACK
F14. ACK
F4. ACK
2-way RTP channel established
F5. 302 Move Temporarily

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
