Yealink SIP-T38G Administrator's Guide

Administrator’s Guide for SIP-T3xG IP Phones
58
Call State
Default Soft Key
Optional Soft Key
Cancel
InConferenceTalk
Empty
Empty
Conference
Cancel
Empty
Switch
Conferenced
Empty
Hold
Split
Cancel
Empty
Switch
Answer
Reject
Mute
Procedure
Softkey layout can be configured using the configuration files or locally.
Configuration File
<y0000000000xx>.cfg
Specify the access URL of the
softkey layout template.
For more information, refer to
Access URL of Softkey Layout
Template on page 313.
Local
Web User Interface
Configure the softkey layout.
Navigate to:
http://<phoneIPAddress>/cgi-bin/
cgiServer.exx?page=Phone-Softk
ey.htm
To configure soft key layout via web user interface:
1. Click on Phone->Softkey Layout.
2. Select the desired value from the pull-down list of Custom SoftKey.
3. Select the desired state from the pull-down list of Call States.
4. In the Unselected Softkeys box, select the desired soft key and click to move
to the Selected Softkeys box.
5. In the Selected Softkeys box, select the undesired soft key and click to move
to the Unselected Softkeys box.

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
