6-21
IM80B80T10E 21th Edition : Jul.1,2007-00
< 6.INSTALLATION >
�VHWdata
The same EML input (dual-axis system)
�VLWdata
The same EML input (dual-axis system)
 In the case of system error detection (*1)
�VBWdata
, , , V , , , V
�VHWdata
, , , , , , N , , K
�VLWdata
, , N , , N
*1: Whenever the A/D conversion error is detected, system error will occur, in case of the EML
input.
Whenever the Communication error No.2 (with the GPS) is detected, system error will occur,
in case of the GPS input.
(In this case, the input mode will be changed the EML input automatically.)
Whenever the any factor is detected, ROM error, RAM error, system error will occur, in all
cases.
