Installation and Adjustment Certicate 1/2
YDK No.:
Yokogawa Denshikiki Co.,Ltd. Electromagnetic Log Model: EML 500-
Name of ship : Installation and Adjustment Period : From to
Owner of ship :
Installed and adjusted at :
Dockyard / Ship No.:
The person in charge :
Ship type / Net tonnage
The company in charge:
On-board power supply : Delivery date of the ship :
G. P. manufacturer / Model
Date of navigation test
GPS manufacturer / Model
Installation and wiring have been conrmed, and nal adjustments have been completed as follows:
LOG No.:
Speed range from- kt to kt.
Dual-indication log :  Longitudinal and transverse speed  Resultant speed and direction of ship movement
Length of measurement rod : L= mm, L1 = mm
Sensor installation :  Single bottom  Double bottom
Sensor dia.:  Ø35  Ø48  Ø70  Other ( mm)
Sensor Protrusion :  50 mm  7 mm  Other ( mm)
Lpp = m
L - m
D = m
B = m
B”
m
B”
m
Intended load line
Nautical speed : kt
