< 2. Specications >
2-7
IM 12F5A1-01E
2.4 Dimensions
Unit: mm
Maintenance
space
Maintenance
space
Maintenance
space
Maintenance
space
Converter
Electric connection
3-ø10.5 holes
(for wall
mounting)
JIS A15 plastic water-proof
plug or equivalent
Drain outlet
(ø15 hose coupling)
Measuring
tank
Needle valve
Sample inlet
(Rc1/4)
2B Pipe
Stanchion
F2.1.5E.ai
Approx. 150
292
144
92
16.5
35
35
29 35
154
Approx.
50
Approx. 110 276 Approx. 160
110
135
48
Figure2.3 DimensionsoftheFC400GFreeAvailableChlorineAnalyzer
