YOKOGAWA FC400G User Manual

< 10. Spare Parts and Consumables >
10-2
IM 12F5A1-01E
10.2.3 IndicatorElectrode(K9332MB)
The indicator electrode is always polished with ceramic beads; it gradually wears and
ultimately becomes unusable. This is the primary factor determining the life of the electrode.
Recommended replacement interval of the indicator electrode is one year generally.
The abrasion-based life may be used as a guidance in providing for indicator electrode
replacement.However,recommendedpracticeistokeeponesparealwaysavailablesincethe
electrode could be inadvertently damaged or otherwise become defective.
The same applies to gold alloy indicator electrode (K9334JP) used in combined chlorine
insensitive version.
Note : Refer to the following : cool storage requirements for electrically-conductive silicon grease for indicator electrode.
[ Applying Electrically-conductive Silicon Grease to Indicator Electrode ]
The indicator electrode needs to be electrically connected to the driven shaft.
This is achieved by applying electrically-conductive silicon grease to the tapped part of the
indicator electrode.
Before use, check that this has been done. If not, apply silicon grease as follows. You can
purchase 3 ml tubes of conductive silicon grease from Yokogawa, the part no. is K9044FX.
Be careful not to get this grease on the outer surface, particularly the gold surface.
Applyasmallquantity(halfadrop)ofgreasetoasmallatscrewdriver(about3mmwideblade)
and apply to three equidistant places around the tapped hole, about 3 to 5 mm inside the tip.
Nextscrewtheindicatorelectrodeintothistapped(threaded)hole.Nextunscrewtheelectrode
andcheckthatnogreasehasbeenextrudedtotheoutersurface.Ifithas,removeitwithacloth
that has been wetted with alkaline soap solution.
NOTE
If the conductive silicon grease gets on the electrode surface, measurement accuracy is likely to
bea󰀨ected.
Conductive silicon grease needs to be applied only once.
10.2.4 CounterElectrode(K9332MK)
The counter electrode does not wear like the indicator electrode ; it can be continuously used
without replacement.
However,recommendedpracticeistokeeponesparealwaysavailable,incaseofaccidental
breakage.
10.2.5 Fuse(A1111EF)
Yearlyfusereplacementintheconverterisrecommendedtoavoidunexpectedoperation
stoppage. Fuse (2A
(Note) Fuse may be used more than one year, we recommend periodical replace for planning maintenance.
