<3. Converter menu>
3-8
IM 12A01G01-03EN 1st Edition : Mar. 25, 2021-00
3.4.2 Lang.(Language)
Read 1.1 Language
3.4.3 Initialization
If you need to reset to factory default, follow this procedure. In a usual operation, you don’t need
the initialization.
CAUTION
Once you initialize the converter, every data of, language, password, device setting is cleared
and reset to default, excluding date/time.
If you want to initialize after conguring some settings, store the data into the memory of
FLXA402T, if necessary. See 5.1.3 Save conguration
To connect a sensor to FLXA402T and display the measurement or mA output, you need to set
up a communication network with sensors or assign each sensor-module address to HMI.
l How to reset parameters
1. On Home/Main screen, tap to go to Converter menu.
2. Press “Setting”.
3. Press “Initialization”.
4. On “Load factory defaults”, nd the sensor module type in use and select.
Connection number is either “1-1” or “1-1+2-1”. Select an appropriate connection to suit
your sensors.
Table 3.1 List example of Load factory defaults
TB TB + PH
CL TB + SC
TB + TB CL + PH
CL + TB CL + SC
CL + CL
5. Conrm the load selection you choose on the step 4. (above) is displayed and tap
“Execute”.
(1) (2) (3)
(4) (5)
Figure 3.7 How to initialize parameters
