3.5 Hold operation (manual Hold)
FLXA402T Hold function retains mA output (mA1/mA2/mA3/mA4) values at preset ones. By
default, Hold keeps values at “Last” set value.
For details on mA output, see 4.3 mA output settings.
For further information on Hold setting see 4.3.3 Congure Hold.
On Converter menu, tap to retain output.
A B
Figure 3.10 Manual Hold
A: appears during Hold of each mA output. Tap again to release the function.
B: appears in the B area which is not yet Hold. Tap to manually HOLD the value.
appears into the A.
l During “Hold”
is displayed on Main screen of the sensor you selected in Process parameter slot. (See
4.3.1)
Figure 3.11 “Hold” on Main screen
If you Tap again, a message pops up asking whether to release the function. After
submitting the conrmation, you will release the Hold function. Automatic HOLD cannot be
released.
You can create password to protect the operation. See 5.4 Password.
