<4. Setting converter>
4-6
IM 12A01G01-03EN 1st Edition : Mar. 25, 2021-00
4.1 mA input settings (Ad)
First select the application of mA input from “Current”, “Temperature”, “pH” or “Conductivity””,
then set 0% value, 100% value of each, according to the application.
This function is available when mA input/output is “-N4” in the sux code. When mA input/output
is “-N2”, mA input is not settable.
If you do not set mA input (Ad), set the application to “None”.
Menu Parameter default Range
lower limit*1 upper limit *2
mA input setting (Ad) Damping time 0.0 s 0 s 3600 s
AI upper limit 20 mA 3.8 mA 20.5 mA
AI lower limit 4 mA 3.8 mA 20.5 mA
Temperature 4 mA 0°C -40.0°C 260.0°C
Temperature 20 mA 100°C -40.0°C 260.0°C
pH 4 mA 0 pH -2 16
pH 20 mA 14 pH -2 16
Conductivity 4 mA 0 S/m 0 S/m 1 S/m
Conductivity 20 mA 0.05 S/m 0 S/m 1 S/m
*1: Congurable lower limit
*2: Congurable upper limit
4.1.1 Type
Select mA input application out of “None”, “Current”, “Temperature”, “pH”, “Conductivity”.
4.1.2 Damping time
This is the time taken for a response to a step input change to reach 90% of the nal value
(attenuation time). The unit is second.
4.1.3 AI Upper Limit/AI Lower Limit
Set AI upper/lower limit for error detection of upper/lower limit. The lower limit must be lower than
the upper one.
4.1.4 Temperature (4 mA/20 mA)
Set each value for 0% (4 mA) and 100% (20 mA) to use mA input as temperature parameter. The
value has to be dierent from each other.
4.1.5 pH (4 mA/20 mA)
Set each value for 0% (4 mA) and 100% (20 mA) to use mA input as pH parameter. The value
has to be dierent from each other.
4.1.6 Conductivity (4 mA/20 mA)
Set each value for 0% (4 mA) and 100% (20 mA) to use mA input as conductivity parameter. The
value has to be dierent from each other.
To Next Page
