YOKOGAWA UT520 User Manual

5-10
<Toc> < 5. Parameters >
IM 05D01C02-41E 3rd Edition: May 31, 2006-00
● Ten-segment Linearizer Parameters
Located in: Main menu =
(PYS1)
Ten-segment
linearizer input
Actual input
Ten-segment
linearizer
biasing
Correction
(Actual input + Ten-
segment linearizer biasing)
1.A1 1.A2 1.A3 1.A4 1.A5 1.A6
1.A7
1.A8
1.B3
1.B4
1.B5
1.B6
-66.7% to 105.0% of PV input range
-66.7% to 105.0% of PV input range
-66.7% to 105.0% of PV input range span
-66.7% to 105.0% of PV input range
1.B1
1.A1 1.A2
1.A3 1.A4 1.A11
The parameters 1.A5 to
1.A11 are equalized to
the parameter 1.A4.
1.B2
1.B3
1.B4
The parameters 1.B5 to
1.B11 are equalized to
the parameter 1.B4.
Ten-segment
linearizer input
Ten-segment
linearizer output
Actual PV input range
● Ten-segment linearizer biasing (factory-set default)
● Ten-segment linearizer approximation
Ten-segment linearizer output
PV input
range after
ten-segment
linearizer
approximation
