YOKOGAWA UT520 User Manual

5-16
<Toc> < 5. Parameters >
IM 05D01C02-41E 3rd Edition: May 31, 2006-00
● Retransmission Output Parameters
Located in: Main menu =
(CMLP)
; Submenu =
(RET)
Parameter
Symbol
Name of Parameter Setting Range and Description Initial Value
Retransmission
output-1 type
OFF (0): Disable
1: PV1, 2: SP1, 3: OUT1, 4: LPS loop power supply (15 V),
5: PV2, 6: SP2, 7: OUT2
Setpoints 5 to 7 are not available for single-loop control.
Retransmission output 1 is always provided via terminals 14
and 15.
In position proportional control, a valve opening signal (0%
to 100%) is transmitted if setpoint “3” is selected.
In heating/cooling control, an output value before allocation
to heating/cooling control (0% to 100%) is transmitted if
setpoint “3” is selected.
(0% to 50%: Cooling-side output; 50% to 100%: Heating-side
output)
1
Maximum value
of retransmission
output-1 scale
RT1=1, 2: TL1 + 1 digit to 100.0% of PV input range
100.0% of PV
input range
User
Setting
Target Item
in CD-ROM
(TH1)
(RT1)
Minimum value
of retransmission
output-1 scale
RT1=1, 2: 0.0% of PV input range to TH1 - 1 digit
0.0% of PV
input range
Retransmission
output-2 type
Retransmission output-2 is available when the type of control
output is not “current” or “voltage pulse.” The output is
provided via terminals 16 and 17.
OFF (0): Disable
1: PV1, 2: SP1, 3: OUT1, 4: LPS loop power supply (15 V),
5: PV2, 6: SP2, 7: OUT2
Setpoints 5 to 7 are not available for single-loop control.
In position proportional control, a valve opening signal (0%
to 100%) is transmitted if setpoint “3” is selected.
In heating/cooling control, an output value before allocation
to heating/cooling control (0% to 100%) is transmitted if
setpoint “3” is selected.
(0% to 50%: Cooling-side output; 50% to 100%: Heating-side
output)
OFF (0)
(TL1)
Maximum value
of retransmission
output-2 scale
RT2=1, 2: TL2 + 1 digit to 100.0% of PV input range
Minimum value
of retransmission
output-2 scale
RT2=1, 2: 0.0% of PV input range to TH2 - 1 digit
(TH2)
(RT2)
(TL2)
Ref.2.2(1)
Ref.2.2(3)
Ref.2.2(1)
Ref.2.2(3)
Ref.2.2(1)
Same as
above
Ref.2.2(1)
Same as
above
