72
IM 01B08B02-01EN
List of Parameters
Parameter Setting Display (PARAMETER)
Parameter Name Setting and Display Range Unit
Factory Default Value
Display and Setting Conditions
for Controller Mode
User
Set-
tings
YS1500
(SINGLE)
YS1700
(PROG)
SINGLE
CAS
SELECT
PROG
PLC1 Square root extraction low cutoff setpoint for PV1 0.0 to 100.0 % 1.0 R/W R/W R/W N/A
PLG1 First order lag time constant for PV1 0.0 to 800.0 s (second) 0.0 R/W R/W R/W N/A
CLC1 Square root extraction low cutoff setpoint for CSV1 0.0 to 100.0 % 1.0 R/W R/W R/W N/A
CLG1 First order lag time constant for CSV1 0.0 to 800.0 s (second) 0.0 R/W R/W R/W N/A
CGN1 Ratio gain for CSV1 -8.000 to 8.000 1.000 R/W R/W R/W N/A
CBI1 Ratio input bias for CSV1 -106.3 to 106.3 % 0.0 R/W R/W R/W N/A
CBO1 Ratio output bias for CSV1 -800.0 to 800.0 % 0.0 R/W R/W R/W N/A
FLG Feedforward lag time constant 0.0 to 800.0 s (second) 0.0 R/W R/W N/A N/A
FGN Feedforward gain -8.000 to 8.000 0.000 R/W R/W N/A N/A
FBI Feedforward input bias -106.3 to 106.3 % 0.0 R/W R/W N/A N/A
FBO Feedforward output bias -800.0 to 800.0 % 0.0 R/W R/W N/A N/A
TLG Tracking input lag time constant 0.0 to 800.0 s (second) 0.0 R/W R/W R/W N/A
PLC2 Square root extraction low cutoff setpoint for PV2 0.0 to 100.0 % (1.0) N/A R/W R/W N/A
PLG2 First order lag time constant of PV2 0.0 to 800.0 s (second) (0.0) N/A R/W R/W N/A
CLC2 Square root extraction low cutoff setpoint for CSV2 0.0 to 100.0 % (1.0) N/A N/A R/W N/A
CLG2 First order lag time constant for CSV2 0.0 to 800.0 s (second) (0.0) N/A N/A R/W N/A
CGN2 Ratio gain for CSV2 -8.000 to 8.000 (1.000) N/A N/A R/W N/A
CBI2 Ratio input bias for CSV2 -106.3 to 106.3 % (0.0) N/A N/A R/W N/A
CBO2 Ratio output bias for CSV2 -800.0 to 800.0 % (0.0) N/A N/A R/W N/A
*The values in () of YS1500 factory default values mean the initial values when the Controller mode is changed to the Selector/Cascade mode.
To Next Page
