Zebra DS2208 Product Reference Guide

RS-232 Interface 8 - 5
RS-232 Host Parameters (continued)
Selecting ICL, Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, OPOS/JPOS, Olivetti, Omron, or
CUTE-LP/LG bar code readers transmits the code ID characters listed in Table 8-3. These code ID characters are
not programmable and are separate from the Transmit Code ID feature. Do not enable the Transmit Code ID
feature for these terminals.
Table 8-3 Terminal Specific Code ID Characters
Code Type ICL Fujitsu
Wincor-
Nixdorf
Mode A
Wincor-Nixdorf
Mode B/
OPOS/JPOS
Olivetti Omron CUTE
UPC-A AAA A AAA
UPC-E EEC C CENone
EAN-8/JAN-8 FF FF B B B FF None
EAN-13/JAN-13 FFA A AFA
Code 39 C <len> None M M M <len> C <len> 3
Code 39 Full ASCII None None M M None None 3
Codabar N <len> None N N N <len> N <len> None
Code 128 L <len> None K K K <len> L <len> 5
I 2 of 5 I <len> None I I I <len> I <len> 1
Code 93 None None L L L <len> None None
D 2 of 5 H <len> None H H H <len> H <len> 2
GS1-128 L <len> None P P P <len> L <len> 5
MSI None None O O O <len> None None
Bookland EAN FFA A AFNone
Trioptic None None None None None None None
Code 11 None None None None None None None
IATA H<len> None H H H<len> H<len> 2
Code 32 None None None None None None None
GS1 DataBar
Variants
None None E E None None None
PDF417 None None Q Q None None 6
Data Matrix None None R R None None 4
GS1 Data Matrix None None W W None None None
QR Codes None None U U None None 7
GS1 QR None None X X None None None

Zebra DS2208 Specifications

General

Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Connectivity technology	Wired
Certification	EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07 IEC 62471 EN 55022 (Class B); EN 55032 (Class B) EN 55024 EN 61000-3-2 EN 61000-3-3 47 CFR Part 15, Subpart B, Class B ICES-003 Issue 6, Class B
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS
Cables included	Micro-USB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery life	100 h
Battery capacity	2400 mAh
Power consumption	250 mA
Power source type	DC
AC adapter output voltage	5 V
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	99 mm
Width	66 mm
Height	165 mm
Weight	161.6 g
