Zebra TC70x User Manual

7 - 2 TC75x User Guide for Android Version 6.0.1
Cradle Mount BRKT-SCRD-SMRK-01 Mounts the 5-Slot Charge Only Cradle, 5-Slot
Ethernet Cradle, and 4-Slot Battery Charger to a
wall or rack.
Batteries and Chargers
4,620 mAh
PowerPrecision+ battery
BTRY-TC7X-46MPP-01
BTRY-TC7X-46MPP-10
Replacement battery (single pack).
Replacement battery (10–pack).
4-Slot Spare Battery
Charger
SAC-TC7X-4BTYPP-01 Charges up to four battery packs. Use with
power supply, p/n PWRS-14000-148R.
Battery Charger Adapter
Cup
CUP-SE-BTYADP1-01 Allows for one 4-Slot Battery Charger to be
charged and docked on the left most slot of the
5-Slot cradles (maximum one per cradle).
Vehicle Solutions
Charging Cable Cup CHG-TC7X-CLA1-01 Provides power to the device from a cigarette
lighter socket.
Charge Only Vehicle Cradle CRD-TC7X-CVCD1-01 Charges and securely holds the device.
Requires power cable CHG-AUTO-CLA1-01 or
CHG-AUTO-HWIRE1-01, sold separately.
TC7X Vehicle
Communication Charging
Cradle
CRD-TC7X-DCVH-01 Provides power for operating the device when
connected to the optional USB I/O Hub and
securely holds the device.
USB I/O Hub SHARE-USBH-01 Provides power to the TC7X Vehicle
Communication Charging Cradle, USB
communication and Requires power cable
CHG-AUTO-CLA1-01 or
CHG-AUTO-HWIRE1-01, sold separately.
TC7X Data Communication
Enabled Vehicle Cradle with
Hub Kit
CRD-TC7X-VCD1-01 Contains the TC7X Vehicle Communication
Charging Cradle and the IUSB I/O Hub.
Cigarette Light Adapter
Auto Charge Cable
CHG-AUTO-CLA1-01 Provides power to the Vehicle Cradle from a
cigarette lighter socket.
Hard-wire Auto Charge
Cable
CHG-AUTO-HWIRE1-01 Provides power to the Vehicle Cradle from the
vehicle's power panel.
RAM Mount RAM-B-166U Provides window mounting option for the Vehicle
Cradle. RAM Twist Lock Suction Cup with
Double Socket Arm and Diamond Base Adapter.
Overall Length: 6.75”.
RAM Mount Base RAM-B-238U RAM 2.43" x 1.31" Diamond Ball base with 1"
ball.
Table 7-1 Accessories (Continued)
Accessory Part Number Description

Zebra TC70x Specifications

General

Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	4.7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Number of cores	6
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Product color	Black
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Rear camera resolution (numeric)	13 MP
Speakers	Mono

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
