Accessories 7 - 47
Device Insertion and Removal
Figure 7-52 Insert and Remove Device into Cradle
To ensure the TC70x/TC75x was inserted correctly, listen for the audible click that signifies that the TC70x/TC75x
locking mechanism was enabled and the TC70x/TC75x was locked into place.
To remove the TC70x/TC75x from the cradle, press the release latch, grasp the TC70x/TC75x and lift out of the
vehicle cradle.
Device Battery Charging
Insert the TC70x/TC75x into the cradle. The TC70x/TC75x starts to charge through the cradle as soon as it is
inserted. This does not deplete the vehicle battery significantly. The battery charges in approximately four hours.
See Table 1-3 on page 1-10 for all charging indications.
Charging Note
The Vehicle Cradle operating temperature is -40°C to +85°C. When in the cradle, the TC70x/TC75x will only
charge when its temperature is between 0°C to +40°C.
CAUTION Ensure that the TC70x/TC75x is fully inserted into the cradle. Lack of proper insertion may result in
property damage or personal injury. Zebra Technologies Corporation is not responsible for any loss
resulting from the use of the products while driving.
