Getting Started 1 - 5
Figure 1-3 TC75x SIM Slot Locations
2. Insert a SIM card into the SIM slot with the cut edge toward the middle of the device and the contacts facing
down.
Figure 1-4 nano SIM Card Installation
Figure 1-5 Mini SIM Card Installation
3. Ensure that the SIM card is seated properly.
Installing the SAM Card
mini SIM/SAM
Slot
nano SIM Slot
1 (default)
nano SIM
Slot 2
CAUTION For proper electrostatic discharge (ESD) precautions to avoid damaging the Secure Access Module
(SAM) card. Proper ESD precautions include, but not limited to, working on an ESD mat and ensuring
that the user is properly grounded.

Zebra TC70x Specifications

General

Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	4.7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Number of cores	6
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Product color	Black
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Rear camera resolution (numeric)	13 MP
Speakers	Mono

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
