Getting Started 1 - 7
Figure 1-8 Insert microSD Card in Holder
4. Re-install the access door.
Installing the Hand Strap and Battery
1. Remove the hand strap filler from the hand strap slot. Store the hand strap filler in a safe place for future
replacement.
Figure 1-9 Remove Filler
2. Insert the hand strap plate into the hand strap slot.
Figure 1-10 Insert Hand Strap
3. Insert the battery, bottom first, into the battery compartment in the back of the TC70x/TC75x.
NOTE Installation of the hand strap is optional. Skip this section if not installing the hand strap.
