7 - 46 TC75x User Guide for Android Version 6.0.1
TC7X Vehicle Communication Charging Cradle
The Vehicle Communication Charging Cradle:
• holds the TC70x/TC75x securely in place
• provides power for operating the TC70x/TC75x
• re-charges the battery in the TC70x/TC75x.
The cradle is powered by the USB I/O Hub.
Refer to the TC70x/TC75x Integrator Guide for Android Version 6.0.1 for information on installing the TC7X Vehicle
Communication Charging Cradle.
Figure 7-51 TC7X Vehicle Communication Charging Cradle
