Getting Started 1 - 9
Figure 1-14 Insert Bottom of Battery into Battery Compartment
2. Press the battery down into the battery compartment until the battery release latches snap into place.
Figure 1-15 Press Down on Battery
Charging the Battery
Before using the TC70x/TC75x for the first time, charge the main battery until the green Charging/Notification light
emitting diode (LED) remains lit. To charge the TC70x/TC75x, use a cable or a cradle with the appropriate power
supply. For information about the accessories available for the TC70x/TC75x, see Chapter 7, Accessories for more
information.
• Snap-On USB Cable
• Charging Cable Cup
• 2-Slot Charge Only Cradle
• 2-Slot USB/Ethernet Cradle
• 5-Slot Charge Only Cradle
• 5-Slot Ethernet Cradle
• Charge Only Vehicle Cradle
• Auto Charging Cable Cup.
• Serial Cable Cup
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). The TC70x/TC75x or accessory always
performs battery charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37°C
(+98°F)) the TC70x/TC75x or accessory may for small periods of time alternately enable and disable battery
charging to keep the battery at acceptable temperatures. The TC70x/TC75x or accessory indicates when charging
is disabled due to abnormal temperatures via its LED.
1. To charge the main battery, connect the charging accessory to the appropriate power source.
2. Insert the TC70x/TC75x into a cradle or attach to a cable. The TC70x/TC75x turns on and begins charging.
The Charging/Notification LED blinks amber while charging, then turns solid green when fully charged.
