Accessories 7 - 43
Vehicle Cradle
Refer to the TC70x/TC75x Integrator Guide for Android Version 6.0.1 for information on installing the Vehicle
Cradle.
The cradle:
• holds the TC70x/TC75x securely in place
• provides power for operating the TC70x/TC75x
• re-charges the battery in the TC70x/TC75x.
The cradle is powered by the vehicle’s 12V or 24V electrical system. The operating voltage range is 9V to 32V and
supplies a maximum current of 3A.
Figure 7-48 Vehicle Cradle
Device Insertion and Removal
To ensure the TC70x/TC75x was inserted correctly, listen for the audible click that signifies that the TC70x/TC75x
locking mechanism was enabled and the TC70x/TC75x was locked into place.
CAUTION Ensure that the TC70x/TC75x is fully inserted into the cradle. Lack of proper insertion may result in
property damage or personal injury. Zebra Technologies Corporation is not responsible for any loss
resulting from the use of the products while driving.
