Getting Started 1 - 13
Figure 1-19 Remove Hand Strap Clip
5. Press the two battery latches in.
6. Lift the battery from the TC70x/TC75x.
7. Lift the access door.
Figure 1-20 Remove Access Door
8. Remove card from holder.
Figure 1-21 Remove Mini SIM/SAM Card
Figure 1-22 Remove Nano SIM Card
