3-134
7. SLED MOVE SIGNAL 1
ZOOM
1.25V
1.25V
0.9V
1.6V
0.9V
12V
12V
1.7V
STEP0
(IC103 PIN8)
STEP1
(IC103 PIN9)
A+(CN102 PIN 2)
A-CN102 PIN 3)
8. SLED MOVE SIGNAL 2
STEP0
(IC103 PIN8)
STEP1
(IC103 PIN9)
A+(CN102 PIN 2)
A-CN102 PIN 3)
