3-146
31. LD Enable(DVD)
LDENDVD(CN101 PIN 17)
LDENCD(CN101 PIN 33)
3.3V
3.3V
32. LD Enable(CD)
LDENDVD(CN101 PIN 17)
LDENCD(CN101 PIN 33)
3.3V
3.3V
