Zenith XBR413 - Focus on Signal(DVD)

3-141
21. FOCUS ON SIGNAL(CD)
F+(REF 2.5V)
(CN101 PIN 35)
FE(REF 1.5V)
(IC107 PIN86)
T+(REF 2.5V)
(CN101 PIN 37)
TE(REF 1.5V)
(IC107 PIN82)
22. FOCUS ON SIGNAL(DVD)
F+(REF 2.5V)
(CN101 PIN 35)
FE(REF 1.5V)
(IC107 PIN86)
T+(REF 2.5V)
(CN101 PIN 37)
TE(REF 1.5V)
(IC107 PIN82)
ZOOM
