Zenith XBR413 - Page 96

3-121
Pin No. Pin Name Type Description
28 DGND 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance
HDD4
29 HDD3 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance]
HDD3
30 HDD11 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance]
HDD12
31 HDD4 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance
HDD2
32 HDD7 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance]
HDD13
33 HDD7 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance].
HDD1
34 DVDD33 - - - Digital power[3.3V]
35 DGND - - - Digital GND
36 HDD9 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance].
HDD14
37 HDD6 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance].
HDD0
38 HDD8 5V_tolerant I/O Pull-up Host interface data bus.[within slave resistance].
HDD15
39 HDD7 5V_tolerant I/O Pull-up Host interface data bus.
40 HRESET 5V_tolerant I/O - Host reset input.
41 TCK 3V I - Test port. It must be connected to DGND.
42 TMS 3V I - Test port. It must be connected to DGND.
43 TAPCLK 3V I - Test port. It must be connected to DGND.
44 TESTSE 3V I - Test port. It must be connected to DGND.
45 DVDD25 - - - Digital power[2.5V]
46 MON3 3V O L Monitor: test signal.
47 MON2 3V O L Monitor: test signal.
48 MON1 3V I/O L Monitor: test signal.
49 MON0 3V I/O L Monitor: test signal.
50 MD15 3V I/O Pull-up Buffer memory , Interface data bus.
51 MD0 3V I/O Pull-up Buffer memory , Interface data bus.
52 MD14 3V I/O Pull-up Buffer memory , Interface data bus.
53 MD1 3V I/O Pull-up Buffer memory , Interface data bus.
54 DVDD33 - - - Digital power.[3.3V](Buffer. Memory. Block)
